| Jumo | Differential | 0bar | 50mbar | - | Analogue | Non-Aggressive Gas | 6 mm Tube | 4 → 20 mA | M12 Connector | - | - | - | - | 230 V ac | - | - | - | IP65 | +50°C | -10°C | - |
|
| Jumo | - | 0bar | 10bar | 0.5 % | - | Hydraulic Fluid, Pneumatic Fluid | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | +80°C | 0°C | - |
|
| Jumo | - | -1bar | 5bar | - | - | - | G1/4 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65/ IP67 | +125°C | -20°C | - |
|
| Jumo | Relative | 0bar | 6bar | 0.5 % | - | Fluid, Gas | G1/4 | 4 → 20 mA | DIN 43650 Connector | - | 3 ms | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65, IP67 | +85°C | -20°C | - |
|
| Jumo | Relative | -1bar | 0bar | - | - | Fluid, Gas | G3/4 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | +100°C | -20°C | - |
|
| Jumo | - | 0bar | 2.5bar | - | - | - | G1/4 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65/ IP67 | +125°C | -20°C | - |
|
| Jumo | - | 0bar | 60bar | 0.5 % | - | Hydraulic Fluid, Pneumatic Fluid | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 15 → 30 V dc | - | Stainless Steel | - | IP65 | +80°C | 0°C | - |
|
| Jumo | Absolute | 0bar | 10bar | 0.5 % | Analogue | - | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | - | - | - |
|
| Jumo | Relative | -1bar | 1bar | 0.5 % | Relay | Non-Corrosive Gas | G1/2 | 4 → 20 mA | M12 Connector | - | 20 ms, 100 ms | 250 mA | - | 12 → 30 V dc | - | Stainless Steel | - | IP67 | +75°C | -25°C | - |
|
| Jumo | Relative | 0bar | 2.5bar | - | - | Fluid, Gas | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | +100°C | -20°C | - |
|
| Jumo | Differential, Gauge, Vacuum | 0bar | 10mbar | - | Relay | Gas | - | - | - | - | - | - | 4304 | - | - | - | - | - | - | - | - |
|
| Jumo | Relative | 0bar | 0.25bar | - | - | Fluid, Gas | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | +100°C | -20°C | - |
|
| Jumo | Relative | 0bar | 60bar | - | - | Fluid, Gas | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | +100°C | -20°C | - |
|
| Jumo | Relative | 0bar | 16bar | - | Analogue | Air | G1/4 | 4 → 20 mA | DIN 43650 Connector | - | 5 ms | - | - | 8 → 30 V dc | - | Stainless Steel | - | - | +125°C | -40°C | - |
|
| Jumo | Absolute | 0bar | 10bar | 0.5 % | Relay | Non-Corrosive Gas | G1/2 | 4 → 20 mA | M12 Connector | - | 20 ms, 100 ms | 250 mA | - | 12 → 30 V dc | - | Stainless Steel | - | IP67 | +75°C | -25°C | - |
|
| Jumo | Absolute | 0bar | 25bar | 0.5 % | - | Fluid, Gas | G1/4 | 4 → 20 mA | DIN 43650 Connector | - | 3 ms | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65, IP67 | +85°C | -20°C | - |
|
| Jumo | Gauge | 0bar | 10bar | ≤0.5 % | Analogue | Gas, Liquid | G1/4 | 4 → 20 mA | Wire Lead | - | ≤3 ms | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP67 | +125°C | -20°C | - |
|
| Jumo | Relative | 0bar | 2.5bar | 0.5 % | Analogue | Fluid, Gas | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | - | - | - | - | - | - |
|
| Jumo | Relative | 0bar | 10bar | 0.5 % | Relay | Non-Corrosive Gas | G1/2 | 4 → 20 mA | M12 Connector | - | 20 ms, 100 ms | 250 mA | - | 12 → 30 V dc | - | Stainless Steel | - | IP67 | +75°C | -25°C | - |
|
| Jumo | Relative | 0bar | 6bar | - | - | Fluid, Gas | G1/2 | 4 → 20 mA | DIN 43650 Connector | - | - | - | - | 10 → 30 V dc | - | Stainless Steel | - | IP65 | +100°C | -20°C | - |
