Littelfuse 30KPA33CA, Bi-Directional TVS Diode, 30kW, 2-Pin P600
- RS Stock No.:
- 171-9484
- Mfr. Part No.:
- 30KPA33CA
- Manufacturer:
- Littelfuse
Bulk discount available
Subtotal (1 unit)**
TWD570.00
(exc. GST)
TWD598.50
(inc. GST)
Temporarily out of stock - back order for despatch 28/08/2025, delivery within 6 working days*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over TWD1,300.00 (ex VAT)
Units | Per unit |
|---|---|
| 1 - 199 | TWD570.00 |
| 200 - 399 | TWD555.00 |
| 400 + | TWD547.00 |
**price indicative
- RS Stock No.:
- 171-9484
- Mfr. Part No.:
- 30KPA33CA
- Manufacturer:
- Littelfuse
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Littelfuse | |
| Diode Configuration | Single | |
| Direction Type | Bi-Directional | |
| Maximum Clamping Voltage | 58.5V | |
| Minimum Breakdown Voltage | 36.9V | |
| Mounting Type | Through Hole | |
| Package Type | P600 | |
| Maximum Reverse Stand-off Voltage | 33V | |
| Pin Count | 2 | |
| Peak Pulse Power Dissipation | 30kW | |
| Maximum Peak Pulse Current | 517.9A | |
| ESD Protection | Yes | |
| Number of Elements per Chip | 1 | |
| Minimum Operating Temperature | -55 °C | |
| Maximum Operating Temperature | +175 °C | |
| Dimensions | 9.1 Dia. x 9.1mm | |
| Surge Current Rating | 400A | |
| Length | 9.1mm | |
| Diameter | 9.1mm | |
| Maximum Reverse Leakage Current | 5mA | |
| Test Current | 50mA | |
