Recom Switching Regulator, PCB Mount, 5V dc Output Voltage, 6.5 → 72V dc Input Voltage, 300mA Output Current, 1
- RS Stock No.:
- 193-6473
- Mfr. Part No.:
- R-78HE5.0-0.3
- Manufacturer:
- Recom
1 / 1
Bulk discount available
Subtotal (1 unit)**
TWD202.00
(exc. GST)
TWD212.10
(inc. GST)
54 In stock for delivery within 6 working days*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over TWD1,300.00 (ex VAT)
Real time qty checker
Units | Per unit |
|---|---|
| 1 - 10 | TWD202.00 |
| 11 - 20 | TWD197.00 |
| 21 + | TWD193.00 |
**price indicative
- RS Stock No.:
- 193-6473
- Mfr. Part No.:
- R-78HE5.0-0.3
- Manufacturer:
- Recom
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Recom | |
| Output Voltage | 5V dc | |
| Output Current | 300mA | |
| Input Voltage | 6.5 → 72V dc | |
| Mounting Type | PCB Mount | |
| Number of Outputs | 1 | |
| Package | SIP 3 | |
| Power Rating | 1.5W | |
| Efficiency | 83% | |
| Ripple And Noise | 150mV Pk-Pk | |
| Maximum Temperature | +105°C | |
| Minimum Temperature | -40°C | |
| Series | R-78HE-0.3 | |
| Line Regulation | ±1.5 (Typ.)% | |
| Depth | 12.5mm | |
| Power Signal Conversion Type | DC-DC | |
| Length | 11.5mm | |
| Current Limiting Method | Hiccup Current Limiting | |
| MTBF | 15000 x 10^3h | |
| Standards Met | REACH Compliant | |
| Load Regulation | 1 (Typ.)% | |
| Width | 8.5mm | |
| Maximum Input Current | 3mA | |
| Switching Frequency Range | 135 (Typ.)kHz | |
| Protection Features | Over Current Protection, Short Circuit Protection | |
| Weight | 2.6g | |
