DFRobot TEL0137 GPS Receiver 160 dBm 1575.42 MHz
- RS Stock No.:
- 247-3250
- Mfr. Part No.:
- TEL0137
- Manufacturer:
- DFRobot
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 247-3250
- Mfr. Part No.:
- TEL0137
- Manufacturer:
- DFRobot
Specifications
Product overview and Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | DFRobot | |
| Product Type | GPS Receiver | |
| Number of Channels | 56 | |
| Acquisition Sensitivity | 160dBm | |
| Tracking Sensitivity | -162dBm | |
| Frequency | 1575.42MHz | |
| Interface Type | USB | |
| Minimum Operating Temperature | -40°C | |
| Time to First Fix - Cold Start | 29s | |
| Protocol | GGA, GSA, GSV, NMEA, RMC, VTG | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand DFRobot | ||
Product Type GPS Receiver | ||
Number of Channels 56 | ||
Acquisition Sensitivity 160dBm | ||
Tracking Sensitivity -162dBm | ||
Frequency 1575.42MHz | ||
Interface Type USB | ||
Minimum Operating Temperature -40°C | ||
Time to First Fix - Cold Start 29s | ||
Protocol GGA, GSA, GSV, NMEA, RMC, VTG | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- CN
The DFRobot GPS receiver brings much more accurate and faster positioning performance with stronger signal compared with traditional GPS receivers. It is compact, lightweight and portable. Integrated with built-in receiving antenna, this product adopts a high-precision positioning chip and industrial-grade manufacturing process so that it can meet the positioning requirements of both industrial-grade and personal use. The GPS receiver has battery inside for supplying power for storing satellite data, such as satellite signal status, final position and time that would greatly increase the positioning speed at the module’s next boot. In addition, this receiver adopts USB interface, which can be conveniently used in main controllers like Raspberry Pi, NVIDIA, LattePanda. It is suitable for vehicle navigation, handheld positioning, wearable devices and other fields.
Update rate 1Hz
Outline dimension 60x24x9mm
Weight 50g
Operating temperature -40℃ to 85℃
Storage Temperature -40℃ to 85℃
Receiving channel 56
