    5.2428Mbps 820nm Fibre Optic Receiver, Round

    Broadcom
    RS Stock No.:
    261-7469
    Mfr. Part No.:
    HFBR-2402Z
    Manufacturer:
    Broadcom
    View all Fibre Optic Receivers
    180 In stock for delivery within 6 working days
    Add to Basket
    units

    Added

    Price (VAT excluded) Each (In a Tube of 60)

    TWD914.60

    (exc. GST)

    TWD960.33

    (inc. GST)

    unitsPer unitPer Tube*
    60 - 60TWD914.60TWD54,876.00
    120 - 240TWD859.90TWD51,594.00
    300 +TWD815.10TWD48,906.00
    *price indicative
    RS Stock No.:
    261-7469
    Mfr. Part No.:
    HFBR-2402Z
    Manufacturer:
    Broadcom

    Product overview and Technical data sheets


    Legislation and Compliance

    COO (Country of Origin):
    PH

    Product Details

    HFBR-14xxZ and HFBR-24xxZ Series Fibre Optic Components


    Optical Receiver for Industrial Applications with Conductive ST-Threaded Port, RoHS Compliant


    The HFBR-0400Z Series of components is designed to provide cost effective, high performance fiber optic communication links for industrial, power generation, power distribution, medical, transportation and gaming applications.

    The HFBR-24x2Z fiber optic receiver is designed to operate with the Broadcom HFBR-14x2Z and HFBR-14x4Z fiber optic transmitter up to 5MBd. This part is characterized with 50/125 μm, 62.5/125 μm, 100/140 μm, and 200 μm HCS® fiber optic cable. HFBR-24x2Z receiver incorporates an integrated photo IC containing a photodetector and dc amplifer driving an open-collector Schottky output transistor.

    This product is also available in other popular industry-standard connectors: SMA, SC and FC.

    Features


    •Low Cost Receiver

    •Integrated Photo IC containing a photodetector and dc amplifier

    •Data Rate up to 5MBd

    •Link Distances up to 2km

    •Specified with 50/125 μm, 62.5/125 μm, 100/140 μm, and 200 mm HCS Fiber

    •Wide Operating Temperature Range -40C to +85C

    •Unique Optical Port Design for Efficient Coupling

    •Auto-Insertable and Wave Solderable

    •No Board Mounting Hardware Required

    Applications


    •Computer to Peripheral Links

    •Computer Monitor Links

    •Digital Cross Connect Links

    •Modems and Multiplexers

    •Suitable for Tempest Systems

    •Industrial Control Links

    Options:


    •HFBR-2412TCZ (Conductive ST-Threaded Port)

    •HFBR-2412TZ (Plastic ST-Threaded Port)

    •HFBR-2412Z (Plastic ST Port)

    The Broadcom 820 nm Miniature Link Series of components is designed to provide cost-effective, high-performance fibber optic communication links for information systems and industrial applications with link distances of several kilometres.

    RoHS compliant
    Low-cost transmitters and receivers
    Choice of ST, SMA, SC, or FC ports
    820 nm wavelength technology
    Signal rates up to 160 MBaud
    Link distances up to several kilometres
    Unique optical port design for efficient coupling
    Pick and place, and wave solder able
    No board-mounting hardware required


    Fibre Optics, Avago Technologies

    Specifications

    AttributeValue
    Maximum Data Rate5.2428Mbps
    Connector ShapeRound
    Wavelength of Peak Sensitivity820nm
    Typical Rise Time4ns
    Typical Fall Time4ns
