Wurth Elektronik 3 Way Through Hole DIP Switch SPST, Raised Actuator, IP67
- RS Stock No.:
- 254-1760
- Mfr. Part No.:
- 418117270903
- Manufacturer:
- Wurth Elektronik
N
View all DIP & SIP Switches
Temporarily out of stock - back order for despatch 29/11/2023, delivery within 6 working days
Price (VAT excluded) Each (In a Tube of 56)
Was TWD40.25
You pay
TWD38.70
(exc. GST)
TWD40.64
(inc. GST)
| units | Per unit | Per Tube* |
| 56 - 56 | TWD38.70 | TWD2,167.20 |
| 112 - 168 | TWD36.60 | TWD2,049.60 |
| 224 + | TWD35.20 | TWD1,971.20 |
| *price indicative | ||
- RS Stock No.:
- 254-1760
- Mfr. Part No.:
- 418117270903
- Manufacturer:
- Wurth Elektronik
- COO (Country of Origin):
- TW
Product overview and Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
The Wurths offers a WS-DITV series of compact THT with raised actuator made up of PBT material with a contact plating of gold with the operating temperature of -40°C to +85°C and an electrical life with 2000 cycles.
Actuator Flammability Rating is UL94 V-0
Operation force is 800 g
Withstanding voltage is 500 V
Operation force is 800 g
Withstanding voltage is 500 V
Specifications
| Attribute | Value |
| Number of Positions | 3 |
| Mounting Type | Through Hole |
| Contact Configuration | SPST |
| Contact Material | Gold |
| Actuator Type | Raised |
| Contact Current Rating | 100 mA |
| IP Rating | IP67 |
