FLIR VT8 Clamp Meter, 100A dc, Max Current 100A ac CAT III 600V
- RS Stock No.:
- 181-2426
- Distrelec Article No.:
- 301-25-653
- Mfr. Part No.:
- VT8-600
- Manufacturer:
- FLIR
Subtotal (1 unit)**
TWD5,248.00
(exc. GST)
TWD5,510.40
(inc. GST)
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over TWD1,300.00 (ex VAT)
Units | Per unit |
|---|---|
| 1 + | TWD5,248.00 |
**price indicative
- RS Stock No.:
- 181-2426
- Distrelec Article No.:
- 301-25-653
- Mfr. Part No.:
- VT8-600
- Manufacturer:
- FLIR
Select all | Attribute | Value |
|---|---|---|
| Brand | FLIR | |
| Absolute Maximum AC Current Measurement | 100A ac | |
| Absolute Maximum DC Current Measurement | 100A dc | |
| Absolute Maximum AC Voltage Measurement | 600V ac | |
| Absolute Maximum DC Voltage Measurement | 600V dc | |
| Absolute Maximum Resistance Measurement | 60MΩ | |
| Model Number | VT8 | |
| AC Current Measurement Resolution | 100mA | |
| DC Current Measurement Resolution | 100mA | |
| Best DC Current Accuracy | ±2.5 % | |
| Clamp Meter Type | AC-DC Open Jaw Clamp Meter | |
| Best AC Current Accuracy | ±2.5 % | |
| Best AC Voltage Accuracy | ±1 % | |
| True RMS | Yes | |
| Best DC Voltage Accuracy | ±1 % | |
| Jaw Capacity Busbars | 15.5mm | |
| Functions Measured | AC Current, AC Voltage, Auto-Ranging, Capacitance, Continuity, Data Hold, DC Current, DC Voltage, DCA Zero, Non-Contact Voltage Detector (NCV), Relative Mode, Resistance, True RMS | |
| AC Voltage Measurement Range | 1000 V | |
| Weight | 163.7g | |
| Safety Category Level | CAT III, CAT IV | |
| Maximum Operating Temperature | +50°C | |
| Display Type | LCD | |
| Best Resistance Measurement Accuracy | ±1.5 % | |
| Safety Category | CAT III 600 V, CAT IV 300V | |
| Battery Type | AA | |
| Safety Category Voltage | 300 V, 600V | |
| Width | 35mm | |
| Power Source | Battery | |
| AC Current Measurement Range | 200 A | |
| AC Voltage Measurement Resolution | 100mV | |
| Height | 53mm | |
| Minimum Operating Temperature | -10°C | |
| DC Voltage Measurement Resolution | 100mV | |
| Dimensions | 210 x 35 x 53mm | |
| DC Current Measurement Range | 200 A | |
| Length | 210mm | |
| Non-Contact Voltage Detector | Yes | |
Select all | ||
|---|---|---|
Brand FLIR | ||
Absolute Maximum AC Current Measurement 100A ac | ||
Absolute Maximum DC Current Measurement 100A dc | ||
Absolute Maximum AC Voltage Measurement 600V ac | ||
Absolute Maximum DC Voltage Measurement 600V dc | ||
Absolute Maximum Resistance Measurement 60MΩ | ||
Model Number VT8 | ||
AC Current Measurement Resolution 100mA | ||
DC Current Measurement Resolution 100mA | ||
Best DC Current Accuracy ±2.5 % | ||
Clamp Meter Type AC-DC Open Jaw Clamp Meter | ||
Best AC Current Accuracy ±2.5 % | ||
Best AC Voltage Accuracy ±1 % | ||
True RMS Yes | ||
Best DC Voltage Accuracy ±1 % | ||
Jaw Capacity Busbars 15.5mm | ||
Functions Measured AC Current, AC Voltage, Auto-Ranging, Capacitance, Continuity, Data Hold, DC Current, DC Voltage, DCA Zero, Non-Contact Voltage Detector (NCV), Relative Mode, Resistance, True RMS | ||
AC Voltage Measurement Range 1000 V | ||
Weight 163.7g | ||
Safety Category Level CAT III, CAT IV | ||
Maximum Operating Temperature +50°C | ||
Display Type LCD | ||
Best Resistance Measurement Accuracy ±1.5 % | ||
Safety Category CAT III 600 V, CAT IV 300V | ||
Battery Type AA | ||
Safety Category Voltage 300 V, 600V | ||
Width 35mm | ||
Power Source Battery | ||
AC Current Measurement Range 200 A | ||
AC Voltage Measurement Resolution 100mV | ||
Height 53mm | ||
Minimum Operating Temperature -10°C | ||
DC Voltage Measurement Resolution 100mV | ||
Dimensions 210 x 35 x 53mm | ||
DC Current Measurement Range 200 A | ||
Length 210mm | ||
Non-Contact Voltage Detector Yes | ||
